Needs & Conditions for Parallel Connection of Transformers

In a power system network, transformers are used to step up and step-down voltage levels. The rating of a transformer is selected according to the load demand. But load demand increases day by day. Hence, to meet extra load demand, we need to change the existing transformer to a higher capacity transformer or we can add an extra transformer connected with the existing transformer.

Related Post: Parallel Operation of DC Generators

The economic way to meet load demand is to connect a second transformer in parallel with the existing transformer.

Table of Contents

Toggle

Need of Parallel Operation of Transformers

The parallel operation of the transformer is needed due to following reasons.

To supply a load of more ratings to the existing transformer, we need to connect the second transformer in parallel with the existing transformer.
At the time of maintenance, a second transformer is used to maintain continuity of supply to the consumer. It increases the reliability of a system.
When one transformer is in fault condition or fails to operate due to any reason, the second transformer is used to supply and avoid intrusion of power.

Conditions for Parallel Operation of Transformers

To ensure the successful parallel operation of the transformers, the following conditions must be satisfying.

The primary winding of both transformers is suitably designed for the supply system voltage and frequency.
Both transformers are connected with the same polarity. If polarities are not matched there is a chance of short-circuiting. Hence, while connecting both transformers in parallel, the polarity of both transformers must match.
The turns ratio (transformation ratio) of both transformers should be identical. It means the voltage rating of primary and secondary windings should be identical. If the turns ratio is not the same, the parallel operation of transformers is possible. But some amount of circulating current will flow in no-load conditions. And it will create unequal loading conditions.
In order to avoid circulating current, the X/R ratio must be the same. It means the impedance triangle must be identical for both transformers. If the X/R ratio is not the same, both transformers will operate on different power factors.
When both transformers have different KVA ratings, the equivalent impedance is inversely proportional to the individual kVA rating (circulating current is ignored).

Parallel Operation of Single-Phase Transformer

Two single-phase transformers can be connected in parallel as shown in the figure below.

As shown in the figure, the primary winding of both transformers is connected with the supply bus bar and the secondary winding of both transformers is connected with the load bus bar. In this way, we can connect two or more than two transformers in parallel and exceed transformer ratings.

While connecting transformers in parallel, the polarities of the transformer must be matched. Otherwise, it will lead to short-circuit and may damage the transformer.

Ideal Condition

In an ideal condition, we consider both transformers have the same voltage ratio and same turns ratio. So, the impedance triangle of both transformers is identical in shape and size. The phasor diagram of this condition is as shown in the figure below.

Where,

E = No-load secondary voltage of each transformer
V₂ = Secondary (load) terminal voltage
V₁ = Primary (supply) terminal voltage
I_A = Current supplied by transformer-1
I_B = Current supplied by transformer-2
I = Total current

As shown in the phasor diagram, the total load current (I) is legging behind V₂ by an angle of ф. And current I_A and I_Bof an individual transformer are in phase with total current (I).

And individual current (I_A and I_B) for each transformer is;

Similarly, current I_B is derived as;

Equal Voltage Ratios

Let’s assume that, the transformers have the same voltage ratio. Hence, no-load voltage of both transformers is equal (E_A = E_B = E). In this condition, no current will flow between two transformers. The equivalent circuit of this condition is as shown in the figure below.

Where,

E_A, E_B = No-load voltage
Z_A, Z_B = Impedances
I_A, I_B = Secondary current of respective transformer
V₂ = Terminal voltage
I = Total current

Here, the impedance of both transformers is connected in parallel. Hence, total impedance Z_AB is;

Vector diagram of this condition is as shown in the figure below.

Here, current I_A and I_B are not in phase. Hence, the total current supplied to the load is a phasor summation of I_A and I_B. And total current (I) is as shown in the vector diagram. Here, we have considered that the no-load voltage of each transformer is the same and it is in-phase in the vector diagram.

Similarly,

Let’s assume Q_A and Q_B are power consumed by each transformer respectively.

Q_A = V₂ I_A and Q_B = V₂ I_B

The total power consumed by both transformers is Q;

Q = V₂ I

Now,

Similarly,

Therefore, Q_A and Q_B are obtained in magnitude and in-phase from the above vectorial equations.

Unequal Voltage Ratio

If the transformation ratio is not the same for both transformers, no-load secondary voltage is not the same. In this condition, some amount of current will flow between transformers in no-load conditions. This current is known as circulating current IC.

Vector diagram of this condition is as shown in the figure below.

The no-load EMF of both transformers is not the same in this condition. Hence,

E_A = I_A Z_A + I Z_L

E_B = I_B Z_B + I Z_L

Where,

Z_L = load impedance

I = I_A + I_B and V₂ = I Z_L

So,

E_A = I_A Z_A + (I_A + I_B) Z_L

E_B = I_B Z_B + (I_A + I_B) Z_L

Subtract the above equations;

E_A – E_B = I_A Z_A – I_B Z_B

(E_A – E_B) + I_B Z_B = I_A Z_A

Put the value of I_A in the equation of E_B;

Similarly,

Now, put the value of total current (I) in the equation of terminal voltage V₂;

The transformer impedances (Z_A and Z_B) are always smaller than the load impedance Z_L. So, to make the equation easy, we neglect Z_AZ_B in comparison with Z_L(Z_A+Z_B).

Parallel Operation of Three-Phase Transformers

In a three-phase transformer also, we can connect two or more than two transformers in parallel to increase load capacity. The conditions required in the parallel operation of a three-phase transformer are the same as a single-phase transformer. Additionally, there is some condition that must be followed.

The phase sequence of both transformers is the same and it is verified by the phase sequence indicator.
Phase displacement between the primary winding and secondary winding must be the same.
All three transformers used in the transformer bank must be the same type of transformer (Core or shell).
While calculating voltage ratio, consider line voltages. And keep the voltage ratio the same.

The There should be a voltage ratio between the primary and secondary terminal voltage. It shows this voltage ratio is not equal to the ratio of number of turns per phase. For example, if V₁ and V₂ are the primary and secondary terminal voltage respectively, then the turn ratio for Star / Delta connection (Y-Δ) would be:

The circuit diagram of the parallel operation of a three-phase transformer is as shown in the figure below.

The primary and secondary winding of both transformers (T1 and T2) are connected as shown in the above figure. Here, the b and c terminals of the secondary winding are kept flexible and connected with a voltmeter for testing purposes. If both voltmeters show zero reading, the polarities are correct. If the voltmeter shows twice of phase voltages, the polarities are wrong.
